Description
This vertical cutting machine prepares foam and other suitable flexible materials before subsequent processing. It is used for cutting material into smaller sections; it is not a foam thickness-splitting machine. The worktable dimensions can be customized to suit your raw material and handling requirements.
Standard 1200 mm Worktable Configuration
| Cutting height | 600 mm |
|---|---|
| Inner worktable | 1200 × 2400 mm |
| Outer worktable | 1200 × 2400 mm |
| Main motor power | 2.2 kW |
| Sharpening motors | 2 × 90 W |
| Wheel arrangement | Four wheels |
| Knife-band width | 25 mm |
| Fence height | 300 mm |
| Standard electrical supply | 380 V, 50 Hz, three-phase |
Worktable Size Options
The following table shows the worktable configurations in this machine series. Both the inner and outer worktables use the dimensions shown for the respective configuration. These are configuration options, not dimensions included together on one machine.
| Model | Each worktable | Cutting height |
|---|---|---|
| GEA-V1000 | 1000 × 2000 mm | 600 mm |
| GEA-V1200 | 1200 × 2400 mm | 600 mm |
| GEA-V1400 | 1400 × 2400 mm | 600 mm |
Customizable Worktables
Worktable dimensions can be customized. Cutting height, electrical supply and machine color can also be reviewed according to your requirements. Please provide the raw-material dimensions, required section sizes and available installation space. The final table size and machine configuration are confirmed for each order.
Plan Material Preparation and Die Cutting
Pre-cutting requirements depend on the material dimensions and the downstream feeding arrangement. Read our EPE foam cutting solutions to compare preparation and die-cutting options.
Send your material and worktable requirements, or explore cutting machine types.
